QUALITY WARRANTY
MUTIFUNCTIONAL
Dimension of host machine
|
3600*1500*2400mm
|
Power of host machine
|
19.2KW
|
Weight of host machine
|
4000kg
|
Vibration force
|
26KN
|
Size of palllet
|
850*550*25mm
|
Model of mixer
|
JQ500
|
Rated Voltage
|
220v/380v
|
Forming period
|
18-20s
|
A
|
NACHINE NAME
|
FUNCTION
|
B
|
QT4-18 brick machine
|
1.pallet feeding system 2.Material feeding system 3.Brick molding system
|
C
|
PLC controller
|
Control the full brick product line by automatic PLC ,full automatic one.
|
D
|
Hydraulic station
|
Supply the hydraulic power for full line
|
E
|
JQ500 Mixer
|
Mix material automatically for brick production
|
F
|
block receiver
|
Convey the completed brick
|
G
|
Stacker, it could layer 4-5 pallets blocks
|
Convey the brick pallet by pallet to the manual trolley
|
H
|
Manual forklift trolley (2 pcs)
|
Convey bricks to curing place
|
Optional systerm
|
Color feeder machine
|
Spread color on bricks(only colored bricks need
|
Size (L*W*H)mm
|
Pcs/mold
|
Pcs/hour
|
400*200*200
|
4
|
600~800
|
240*115*53
|
26
|
5000~5200
|
200*100*60
|
14
|
4600~4800
|
