SC Invech Diesel Plate Compactor Reversible Plate Compactor
The use of plate compactor is mainly used for compacting engineering foundations and road surfaces in highways, municipalities, and construction. Suitable for groove backfill foundation, asphalt compaction, floor tile compaction, etc.
Product Characteristics
(1)Compact perfect appearance
(2)Easy to move and high efficiency
(3)Good compaction
(4)Save energy
Technical Parameter
| Plate Compactor [ diesel type ] | |
| Model | IVPC-200 (Diesel) |
| Engine | QUANRUN Diesel Engine |
| Power | 6.5 HP |
| Oil consumption | 0.5L/H |
| Working area | 450*600 mm |
| Walking mode | one-way |
| Vibrating force | 30 kn |
| Frequency | 70 Hz |
| Compaction depth | 400 mm |
| Grade ability | 25% |
| Forward Speed | 6-16 m/min |
| Size | 600*450*1200 mm |
| Weight | 120 kg |
| Model | IVPC-250 (Diesel) |
| Engine | QUANRUN Diesel Engine |
| Power | 6.5 HP |
| Oil consumption | 0.5L/H |
| Working area | 420*640 mm |
| Walking mode | one-way |
| Vibrating force | 30 kn |
| Frequency | 70 Hz |
| Compaction depth | 400 mm |
| Grade ability | 25% |
| Forward Speed | 6-16 m/min |
| Size | 640*420*1200 mm |
| Weight | 140 kg |
Gasoline and Electric Type for Recommendation:
|
Model |
IV-60 |
IV-90 |
IV-160 |
IV-120 |
IV-150 |
|
Power type |
Gasoline |
Gasoline |
Gasoline |
Electric |
Electric |
|
Power output(kw) |
5.5 |
5.5 |
7.5 |
3 |
4 |
|
Exciting force(km) |
10.5 |
13 |
30 |
16 |
20 |
|
Compaction depth(cm) |
20 |
30 |
30 |
30 |
30 |
|
Moving speed(cm/s) |
4 |
4 |
10 |
10-27 |
10-27 |
|
Working efficiency |
450 |
660 |
550 |
48Hz |
48Hz |
|
Dimension(mm) |
800*100*1080 |
850*500*1100 |
500*400*1000 |
450*420 (Compaction area) |
450*420 (Compaction area) |
|
Item weight(kg) |
62 |
83 |
180 |
125 |
150 |
|
Gradeability |
≤20 |
≤20 |
≤20 |
≤20 |
≤20 |
